Camera Image Sensor 1/2.8″ CMOS Pixel 2 MP Max. Resolution 1920 (H) × 1080 (V) ROM 128 MB RAM 128 MB Electronic Shutter Speed 1/3 s–1/100,000 s Scanning System Progressive Min. Illumination Color: 0.05 [email protected] B/W: 0.005 [email protected] 0 lux (IR/white light on) Illumination Distance 30 m (98.42 ft) (IR) 30 m (98.42 ft) (white light) Illuminator On/Off Control Manual; auto; off Illuminator Number 2 (IR light) 2 (White light) Lens Focal Length 4.0 mm Max. Aperture F2.0 Field of View H: 86.8° V: 47.1° D: 102.2° Close Focus Distance 0.6 m (1.97 ft) Iris Control Fixed DORI Distance Detect Observe Recognize Identify 53.6 m (175.85 ft) 21.4 m (70.21 ft) 10.7 m (35.10 ft) 5.4 m (17.72 ft) PTZ Pan/Tilt Range Pan: 0° –345° Tilt: 0° –80° Manual Control Speed Pan: 0.1°–74°/s Tilt: 0.1°–36.4°/s Preset Speed Pan: 62°/s Tilt: 36.3°/s Preset 300 Power-off Memory Yes Idle Motion Preset Smart Event IVS Tripwire; intrusion Human Detection Yes Active Deterrence Light Warning White light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low Sound Warning Sound warning alarm: Customizable Alarm duration: 10 s, 20 s, 30 s Video Video Compression H.264B; Smart H.265 ; H.264; H.265; MJPEG (Sub Stream); Smart H.264 Streaming Capability 2 streams Resolution 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) Video Frame Rate Main stream: 1080p/1.3M/720p (1–25/30 fps) Sub stream: D1/CIF (1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H264: 256–8192 kbps H265: 144–5632 kpbs Day/Night Auto (ICR)/Color/B/W BLC Yes WDR DWDR HLC Yes White Balance Auto; manual; tracking; indoor; outdoor; sodium lamp; street lamp; natural light Gain Control Auto; manual Noise Reduction 2D NR; 3D NR Motion Detection Yes Image Rotation 180° S/N Ratio ≥ 55 dB Audio Audio Compression PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1 Network Network Port RJ-45 (10/100 Base-T) Wi-Fi Yes Wi-Fi–Wireless Standard 802.11n; IEEE802.11b; 802.11g Wi-Fi–Wireless Frequency Range 2.4 GHz Wi-Fi–Wireless Transmission Rate 150 Mbps Network Protocol UDP; FTP; RTMP; IPv6; IPv4; IP Filter; DNS; RTCP; HTTP; NTP; SSL; DHCP; RTP; SMTP; HTTPS; TCP/IP; RTSP; DDNS; ARP Interoperability CGI; SDK; ONVIF (Profile S&T); P2P Streaming Method Unicast/Multicast User/Host 20 Storage Micro SD card (512 GB); FTP Browser IE: IE 7 and later versions; Chrome; Firefox; Safari Management Software DMSS Mobile Client iOS; Android Certification Certifications CE:EN55032/EN50130-4/EN IEC61000-3-3/EN IEC61000-3-2/EN55024/EN55035/EN62368-1 FCC:47 CFR FCC Part15, Subpart B, ANSI C63.4:2014 Port Audio Input 1 channel (built-in mic) Audio Output 1 channel (built-in speaker) Two-way Audio Yes Alarm Linkage Capture; preset; recording; audio; sending email Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection Audio I/O 1/1 Power Power Supply 12 VDC/1.5 A±10% Power Consumption Basic: 3.5 W Max.: 11 W (illuminator PT speaker heating glass) Environment Operating Temperature –30 °C to 55 °C (–22 °F to 131 °F) Operating Humidity ≤ 95% Protection IP66, TVS 2000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 140.5 mm × Φ111.0 mm (5.53″ × Φ4.45″) Net Weight 0.5 kg (1.10 lb) Gross Weight 1 kg (2.20 lb) SKU: DH-SD2A200HB-GN-AW-PV-S2 Category: Dahua IMOU Wifi Camera
