Camera Image Sensor 1/3″ CMOS Max. Resolution 1920 (H) × 1080 (V) ROM 16 MB RAM 64 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.005 [email protected] (Color, 30 IRE) 0.0005 [email protected](B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance Up to 30 m (98.53 ft) Illuminator On/Off Control Auto Illuminator Number 2 (Warm light) Angle Adjustment Pan: 0°–360° Tilt: –60°–45° Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm;3.6 mm Max. Aperture F1.6 Field of View 2.8 mm: H: 98°; V: 55°; D: 115° 3.6 mm: H: 78°; V: 41°; D: 94° Iris Control Fixed Close Focus Distance 2.8 mm: 1 m (3.28 ft) 3.6 mm: 1.7 m (5.58 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 61.2 m (200.78 ft) 24.5 m (80.38 ft) 12.2 m (40.03 ft) 6.1 m (20.01 ft) 3.6 mm 85.4 m (280.18 ft) 34.2 m (112.20 ft) 17.1 m (56.10 ft) 8.5 m (27.89 ft) Intelligence Human Detection Support the classification and accurate detection of human Video Video Compression H.264B; H.264; H.264H; H.265 Smart Codec Smart H.265 ; Smart H.264 Video Frame Rate Main stream: 1920 × 1080@(1–25/30 fps) Sub stream: 640 × 480@(1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 2 streams Resolution 1080p (1920 ×1080); 1280 × 960 (1280 × 960); 1280 × 720 (1280 × 720) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32kbps ~ 4096kbps H.265: 12kbps ~ 4096kbps Day/Night Color/B/W BLC Yes HLC Yes WDR DWDR White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Smart Illumination Yes Image Rotation 0°/180° Mirror Yes Privacy Masking 4 areas Audio Built-in MIC Yes, built-in Mic Audio Compression G.711a; G.711Mu; PCM; G.726 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; abnormal audio input; intensity change; motion detection; SMD(human) Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G SDK and API Yes Network Protocol IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP; P2P Interoperability ONVIF (Profile S; Profile G); CGI User/Host 20 (Total bandwidth: 64 M) Storage Micro SD card (support max. 256 GB) Browser IE; Chrome; Firefox Management Software Smart PSS; DSS; DMSS Mobile Client iOS;Android Cyber Security Configuration encryption;trusted execution;Digest;security logs;HTTPS;trusted upgrade;WSSE;trusted boot;account lockout;generation and importing of X.509 certification;video encryption Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU Power Power Supply 12 VDC Power Consumption Basic: 2 W (12 VDC) Max. (H.265 warm light intensity): 5.3 W (12 VDC) Environment Operating Temperature –40 °C to 60 °C (–40 °F to 140 °F) Operating Humidity ≤95% Storage Temperature –30 °C to 60 °C (–22 °F to 140 °F) Storage Humidity ≤95% Protection IP67 Structure Casing Material Metal plastic Product Dimensions 131.0 mm × 78.4 mm × 97.2 mm (5.47″ × 4.80″ × 3.83″) (L × W × H) Net Weight 254.5 g (0.56 lb) Gross Weight 503 g (1.11 lb) SKU: DH-F2C-LED Category: Dahua IMOU Wifi Camera
